Products Description
The BW1200/7 mud pump is a horizontal, double-cylinder, double-acting reciprocating piston pump designed for geological drilling, geothermal exploration, water source investigation, and shallow oil and coalbed methane extraction. It offers adjustable flow and pressure by replacing cylinder sleeves, piston sleeves, and pistons of varying diameters to meet different drilling requirements.
Featuring a simple structure, the pump is easy to operate and maintain. It comes equipped with a seismic pressure gauge, essential spare parts, and disassembly tools to ensure long-term, stable operation. Depending on customer needs, the BW1200/7 mud pump can be configured with an electric motor, diesel engine, or hydraulic motor drive, providing good adaptability and flexibility.
This mud pump is suitable for water well drilling, core drilling for oil wells, and cleaning operations up to depths of 1,500 meters. It is also capable of supplying mud to oil drilling stations. By selecting different cylinder and piston sizes, users can fine-tune the pump's performance to match specific project demands and maximize operational efficiency.
Products Parameters
|
Pattern |
Horizontal double-cylinder reciprocating double-acting piston pump |
|
|
Cylinder dia(mm) |
160 |
150 |
|
Flow(L/min) |
1200 |
1000 |
|
Rated Output Pressure (Mpa) |
7 |
6 |
|
Stroke(mm) |
270 |
|
|
Rated Pump Speed(min-1) |
70 |
|
|
Power (KW) |
185 |
|
|
Weight(kg) |
7200 (without engine) |
|
|
Dimension(mm) |
3045*1440*2420 |
|
Packaging & Shipping
Delivery time: 10-15days
We use professional equipment to frame the boxes. We will arrange a specially-assigned person to inspect every step. Ensure transportation safety.
Application
The BW1200/7 mud pump is widely used in construction drilling, geological surveys, mineral and coal exploration, water well drilling, geothermal pipeline installation, and foundation piling. It is well-suited for deep water wells, core drilling in oil wells, and a variety of drilling applications. The pump provides efficient delivery of flushing fluids, helping to ensure smooth and continuous drilling operations.
Certificate
Our products have passed CE certification and ISO9001 quality management system certification, ensuring that they meet international standards in terms of safety, reliability and quality.
A One-stop solution
When choosing the right BW slurry pump model, you need to make a decision based on the specific usage scenario, required flow, working pressure, budget and other factors. For example, if your project is in a mine or large-scale project, you may need to choose a model with higher power and flow; while for general slurry delivery tasks, the BW160 may be sufficient to meet the needs. We offer a variety of models of slurry pumps and drilling rigs to provide you with a one-stop solution. If you have any questions, please feel free to contact us and we will recommend the most suitable equipment for you.
