Rotary Drilling Rig
Your Professional Rotary Drilling Rig Supplier
We are your trusted Rotary Drilling Rig manufacturer, Henan Rancheng Machinery Co., Ltd. provides customers with one-stop procurement services with a first-class office environment and efficient and orderly production lines, at the same time, we are equipped with more than 100 sets of advanced manufacturing equipment, the main product lines are unique, covering water well drilling rigs, professional drilling rigs, high-efficiency anchoring drilling rigs, powerful deep hole percussion drilling rigs, flexible rotary drilling rigs, innovative solar piling rigs, reliable mud pumps, efficient air compressors, diversified drilling tools, etc. Not only does it meet a variety of industrial and architectural needs, but it is also designed with a focus on innovation and practicality to ensure that users get the best possible efficiency and experience. With competitive price and reliable quality, it has won a good reputation.
Our factory
The company is located in a modern industrial park covering an area of 20,000 square meters, with a first-class office environment and efficient and orderly production lines, more than 200 elites gathered here, the technical team LED by more than 20 senior technicians, constantly leading the industry technological innovation, and equipped with more than 100 sets of advanced manufacturing equipment to ensure efficient production and excellent quality.
Our products
Our main product lines are unique, including water well drilling rigs, professional drilling rigs, high-efficiency anchoring drilling rigs, powerful deep hole percussion drilling rigs, flexible rotating drilling rigs, innovative solar piling rigs, reliable mud pumps, high-efficiency air compressors, diversified drilling tools, etc.
Our certificates
Our products are of excellent quality and outstanding performance, and have obtained many authoritative certifications such as iso9001 and ce.
Production market
With competitive prices and reliable quality, our products have been exported to africa, south america, southeast asia, eastern europe and other countries and regions. We have established long-term cooperative relationships with our customers and won a good reputation.
Advantages of Rotary Drilling Rig
Speed
Rotary drilling is a fast method. In fact, it is significantly quicker than numerous other conventional drilling techniques. Importantly, it also delivers high-integrity results and does not compromise on quality.
Reliable
The rigs are highly dependable. Rotary drilling is a method that has been used for millennia so it has been refined over time.
Flexibility
Rotary drilling rigs are so simple to operate. Their ease of set-up, dismount and ability to be transported, means they are well-known as every geotechnical company’s dream to work with.
Application and Configuration of Rotary Drilling Rig
|
Method |
Configuration |
Application |
|
Steel Casing Drive |
Telescopic friction drill pipe, digging drilling tools, connecting flower tubes |
Drilling into backfill soil, sand, pebble, and limestone while preventing hole collapse and water leakage. |
|
Rotary Drilling Rig with Pipe Rubbing Machine |
Telescopic drill pipe, rotary drilling tools, detachable pressure plate |
Efficiently drilling larger casings with accurate concrete control and safe, environmentally friendly processes. |
|
Long Spiral Configuration and Application |
Long auger drilling tool, moving pulley, concrete delivery elbow |
Continuous slag discharge in pile construction with core extraction in rock drilling, suitable for high strength formations. |
|
Gas Lift Reverse Circulation Drilling into Rock |
Rotating air chamber, telescopic machine lock drill pipe |
Reverse circulation drilling for effective hard rock excavation while maintaining high environmental standards. |
|
Middle Excavation Method |
Movable pulley, concrete delivery elbow, lower power head |
Stable drilling near tall buildings with casing support, ensuring minimal disturbance and eco-friendly construction. |
|
Extrusion Expansion Disc Forming Machine/Bottom |
Hose reel, friction telescopic drill pipe, hydraulic hose |
Innovative extruded and expanded branch pile technology for increased bearing capacity, cost savings, and faster construction. |
Correct and Safe Operation Procedures for Rotary Drilling Rig
Application precautions
a. After starting the engine, operate at low speed for 3-5 minutes, and turn the power head under no load, so as to facilitate the normal operation of the hydraulic system.
b. During the operation of the drilling rig, the operator shall often check whether various appearance indications are normal. If there are abnormal conditions, the drilling rig shall be stopped in time for inspection.
c. During the handling of the drilling rig, the crawler needs to be opened after getting off the flatbed truck.
d. When welding drill pipe parts, it is necessary to turn off the power switch.
e. Check the reverse connector regularly.
Rig assembly and disassembly
a. Before the assembly and disassembly of the drilling rig, the mechanical technicians must formulate detailed implementation plans and safety measures according to the operation instructions of the manufacturer and strictly implement them.
b. The hoisting of components shall be commanded by professionals, and the corresponding steel wire rope shall be selected according to the detailed weight. It is forbidden to assemble or disassemble the drilling rig under strong wind, heavy rain or unclear lifting vision.
c. When assembling the drilling rig, ensure that the base of the drilling rig is horizontal and firm.
d. After assembly, thoroughly check and adjust the straightness of the drill frame, and the center error of the drill pipe shall meet the construction requirements.
Preparation before drilling
a. All bolts shall be complete, intact and fastened.
b. The condition and smooth curing condition of the steel wire rope shall meet the requirements. The appearance of the steel wire rope shall be inspected once a week, and a thorough and detailed inspection shall be conducted at least once a week.
c. The oil level height of the main and auxiliary hydraulic oil tank, rotary table, power head and fuel tank of the drilling rig shall be within the range specified in the manual, and shall be increased in time in case of lack. Check the oil quality. If the oil is deteriorated, it should be replaced immediately.
Technical Specification
|
Type |
Rotary Drilling Rig |
|
|
Drilling depth |
30m |
|
|
Hole diameter |
500-1600 mm |
|
|
Engine |
Brand |
Cummins |
|
Power |
210HP (154KW) |
|
|
Power Head |
Torque |
130 KN ·m |
|
Rotating speed |
10-50 r/min |
|
|
Main Winch |
Maximum lifting force |
150 KN |
|
Lifting speed |
70 m/ min |
|
|
Wire rope diameter |
24 mm |
|
|
Vice Winch |
Maximum lifting force |
30 KN |
|
Lifting speed |
55 m/ min |
|
|
Wire rope diameter |
14 mm |
|
|
Pressurized Cylinder |
Maximum pressure |
120 KN |
|
Max lifting speed |
120 KN |
|
|
Stroke |
2500 mm |
|
|
Walk |
Walk speed |
5 km/h |
|
Maximum grade |
30 ° |
|
|
System pressure |
32 Mpa |
|
|
Weight |
28 / 30 T |
|
|
Working Radius |
4.3 m |
|
|
Dimensions (L * W * H) |
11.5 m*3 (2.8-3.6)m*3.55m |
|
|
Type |
HF30+ Rotary Drilling Rig |
|
|
Drilling depth |
30m |
|
Packaging & Delivery
|
Package Size |
9500.00cm * 2200.00cm * 3400.00cm |
|
Package Gross Weight |
8500.000kg |
Transportation of Rotary Drilling Rig
Drill sites can be found all over the world, often in some very remote areas. Getting equipment to these sites can be tough. It’s always interesting to learn about the various methods of transport equipment suppliers and drilling companies use. Some of these methods may surprise you.
Many manufacturers will ship to the nearest train yard, bus stop, delivery service depot or building. After that the drilling companies use some creativity in making sure the equipment reaches the site.
