Products Description
Diamond PDC Bit is highly efficient for high-speed drilling, particularly in shale, limestone, and sandstone formations. Unlike traditional roller cone bits, diamond PDC Bit has a single-body design with no moving parts. This fixed-cutter structure allows them to shave away rock, enabling faster rotational speeds and improved drilling efficiency, especially in consolidated formations.
The four-wing diamond PDC bit is specifically designed for soft to medium-hard formations. Its bit body is constructed from high-quality alloy steel, providing excellent strength and toughness. Additionally, the surface is reinforced to prevent erosion, significantly extending the bit's service life.
products parameters
| Types of diamond PDC bit & Application | ||
| Type | Application | |
| PDC 4-wing Drill Bit | Normal | Fit for f<6 rock formations |
| Reinforced | Fit for f<8 rock formations | |
| PDC Multi-wing Drill Bit Normal | Normal | Fit for f<6 rock formations |
| Reinforced | Fit for f<8 rock formations | |
| diamond PDC bit Specifications | |||||||
| Type | Size (mm) | Height (mm) | Wing(s) (pcs) | PCD Cutter (pcs) | Nozzle (pcs) | Nozzle Size (mm) | |
| Normal Reinforced | 94 | 170 | 4 | 16 | 5 | 6 | |
| 113 | 195 | 4 | 20 | 5 | 8 | ||
| 133 | 220 | 6 | 30 | 5 | 8 | ||
| 153 | 250 | 6 | 36 | 5 | 1 | ||
Products features
Medium short parabolic profile with medium cutter density helps to obtain better ROP in soft to medium hard formations with lower compressive strength and small hard layers.
Cutting structure is force balanced and the bit blade is asymmetrically designed so that the load on the bit is balanced that resulting in better stability of the bit.
Main cutters are high-performance PDC cutters to ensure the service life of the bit while improving ROP.
Cutter exposure is optimized to ensure the bit can achieve higher ROP in soft to medium formations.
Shock absorbers are designed to make the bit capable of drilling through formations with hard stringers. Hydraulic system of the bit is optimized using dynamic flow pattern simulation technology to enhance the cleaning and cooling effects of the bit to effectively prevent the bit from balling.
application
Four wings diamond PDC bit is used for coal mining, oilfield, water conservancy and hydropower, construction of road and building.
